1 Bedroom Flat
1 Bedroom Flat Zone Size m Area m2 Master Bedroom 4.5 x 2.9 + 1.0 x 1.5 14.6 Bathroom 2.9 x 2.4 7.0 Kitchen 3.9 x 2.1 9.0 Living Room 4.2 x 3.7 15.0 Entrance Lobby 1.5 x 3.8 5.7 Storage 1.3 x 0.9 1.2 Total Area 52.5
26Jun
10Sep
5 Bedroom House
5 Bedroom House Ground Floor Zone Size m Area m2 Master Bedroom 3.1 x 5.3 16.4 WC 2.8 x 2.4 6.7 Kitchen 5 x 3.1 15.5 Dining Room 4 x 2.3 9.2 Living Room 4 x 3.8 15.2 Entrance Lobby 2.2 x 3.2 7.0 Circulation 7.8 Storage / Lift 1.4 x 1.1 1.5 Total Area 79.3 Total Area (with First Floor) 151.7 First Floor Zone Size m Area m2 Bedroom 2 3.2 x 3.5 11.2 Bedroom 3 3.1 x 3.8 11.8 Bedroom 4 3.0 x 3.8 11.4 Bedroom 5 3.0 x 3.8 11.4 Bathroom 2.2 x 3.5 5.6 Circulation 14.0 Storage 1 1.4 x 1.5 2.1 Boiler / Storage 1.4 x...
22May
Windows & Doors
Windows & Doors Windows & doors should harmonise with the scale, size and form of the proposed building but also and more importantly, neighbouring buildings. Windows should be of a size to ensure good levels of daylight can penetrate into the building creating Beautiful spaces that promotes mental health and wellbeing....
22May
Communal Space
Communal Space Circulation areas within a building should be designed to be Accessible, Beautiful, Connected and useable by as wide a range of people as possible, including use by a person in a wheelchair allowing occupants to move around freely and without difficulty, to the best of their ability. The entrance to...
22May
2 Bedroom Flat
2 Bedroom Flat – Standard Zone Size m Area m2 Master Bedroom 3.1 x 4.3 13.3 Bedroom 2 3.1 x 3.8 11.8 Bathroom 2.7 x 2.4 6.5 Kitchen 3.4 x 3.5 11.9 Dining Room 3.2 x 2.2 7.0 Living Room 3.5 x 4.5 15.8 Entrance Lobby 3.0 x 1.9 5.7 External Balcony 3.1 x 1.5 4.7 Total Area 76.7
22May
Space Standards
Space Standards The Blackwood “Concept House” was created to explore solutions for an Accessible , adaptable, Affordable and Beautiful dwelling based around accommodation offering a double bedroom with carer/second bedroom. Early during development, this translated to the 70m2 2 bed / 2 person solution delivered at Glamis Road in Dundee, plans for...
22May
4 Bedroom House
4 Bedroom House Ground Floor Zone Size m Area m2 Master Bedroom 3.1 x 4.7 14.6 Bathroom 1 2.7 x 2.4 6.5 Kitchen 3.3 x 3.5 11.6 Dining Room 3.1 x 2.2 6.8 Living Room 3.5 x 4.9 17.2 Entrance Lobby 3.0 x 2.2 6.6 Circulation 3.2 x 3.6 11.5 Storage / Lift 1.8 x 1.3 2.3 WC 1.7 x 1.2 2.0 Total Area 79.1 Total Area (with First Floor) 134.2 First Floor Zone Size m Area m2 Bedroom 2 3.3 x 4.7 15.5 Bedroom 3 2.8 x 3.4 9.5 Bedroom 4 3.1 x 2.2 6.8 Bathroom 2 2.8 x 2.5 7.0 Circulation 2.8 x 5.0 14.0 Storage / Lift 1.8 x 1.3 2.3 Total...
22May
Arrangement
Arrangement Configuration of building allows to achieve the desired minimum dual aspect Flexibility of design allows the Blackwood House to be stacked easily and grouped Due to the fixed bathroom, kitchen core and flexible space around, site specific restrictions can be overcome by adapting the outer walls. Orientation of layout to allow main living...
